Your Professional Mining Hoses Supplier
Shanghai DER New Material Co., Ltd is built under EU standard at its production and physical testing methods. production area 60,000 square meter, registered with 2.5 million US dollars. 3 calendars, 1 knife coating machine, 2 hot melt machine and 5 lamination machine, 25 senior engineers and 450 workers make our factory more competitive among the Coated fabric supplies.
Features
- PVC Laminated Fabric: It is fire retardant, different thickness of pvc laminated fabric for customers to choose. 0.35mm is standard thickness for duct. This main material for duct is manufactured by ourselves.
- Wire Steel: The diameter of wire steel for flexible duct is according to the size of duct. For exsample, 200mm diameter flexible duct is manufactured by 1.80mm diameter wire steel, 300mm diameter of flexible duct is manufactured by 2.20mm diameter wire steel.
- Rubber Wear Stripe: It is manufactured by ourselves, the standard color of it is black. It is customized.
- D Rings: There are two big D rings for one piece of duct. Both of these two big D rings on the edge of the duct. And there is a small D ring per meter on the duct.
- OEM: OEM service can be offered freely in our factory. Logos can be sticked on the duct and printed on the carton.
- Sample can be sent, but for the shipping freight of sample will be paid by customer first, and if there is order in the near future, the cost of shipping the sample will be returned.
Product Description
| Diameter Available | 150mm/ 300mm/ 350mm/ 400mm/ 450mm/ 500 mm/ 600mm/800mm/ 1000 mm/ 1200mm/ 1500mm/ 1800mm/ 2000mm/ 2200m |
| Dust Length | 5m / 10m / 20m/ 30m |
| Material | PVC fabric |
| Color Available | Multiple Colour |
| Function | Anti-flaming, Anti-static, three-tee blowing-in |
|
Base Fabric |
Weight (gsm) |
450 |
550 |
650 |
700 |
700 |
|
Yarn count |
1000D |
1000D |
1300D |
1300D |
1000*2000D |
|
|
Construction |
9*9 |
12*12 |
12*12 |
12*12 |
20*10 |
|
|
Tensile |
Warp N/5CM |
1500 |
1700 |
2400 |
2400 |
2600 |
|
Weft N/5CM |
1400 |
1600 |
2300 |
2300 |
2600 |
|
|
Tear |
Warp N/5CM |
160 |
260 |
300 |
300 |
300 |
|
Weft N/5CM |
150 |
250 |
280 |
280 |
300 |
|
|
Adhesion |
N/5CM |
90 |
100 |
100 |
100 |
100 |
Ordering notice
|
Before place an order, please send us following parameters to help us find the most suitable Flexible duct for you: |
|
|
1 |
Diameter and air supply distance |
|
2 |
Color (orange, green, black) |
|
3 |
Connection method |
|
4 |
Inlet and outlet dimensions of TEES, bifurcation angle |
Frequently Asked Questions
Q: How durable are the tarpaulins? What kind of warranty do you offer?
Q: How durable are the tarpaulins? What kind of warranty do you offer?
A: Durability and Warranty: Our tarpaulins are designed to be durable, waterproof, and UV resistant. We stand behind the quality of our products and offer a warranty against manufacturing defects.
Q: Are the tarpaulins waterproof and UV resistant?
Q: Are the tarpaulins waterproof and UV resistant?
A: Waterproof and UV Resistance: Yes, our tarpaulins are engineered to be waterproof and provide UV protection, ensuring long-lasting performance in various weather conditions.
Q: Can the tarpaulins be customized with logos or specific designs?
Q: Can the tarpaulins be customized with logos or specific designs?
A: Customization: We can customize tarpaulins with logos or specific designs based on your requirements. Please contact us for more information on customization options.
Q: What are the recommended uses for your tarpaulin products?
Q: What are the recommended uses for your tarpaulin products?
A: Recommended Uses: Our tarpaulin products are suitable for various applications, including covering equipment, vehicles, construction sites, and outdoor storage.
Q: How should the tarpaulins be cleaned and maintained?
Q: How should the tarpaulins be cleaned and maintained?
A: Cleaning and Maintenance: Tarpaulins can be cleaned with mild soap and water. Regular maintenance, such as proper storage when not in use, can extend the lifespan of the tarpaulins.
Q: What is the expected lifespan of your tarpaulin products?
Q: What is the expected lifespan of your tarpaulin products?
A: Lifespan: The lifespan of our tarpaulin products depends on usage and maintenance but they are built to be long-lasting and withstand tough conditions.
Q: Do you offer bulk pricing or wholesale discounts?
Q: Do you offer bulk pricing or wholesale discounts?
A: Bulk Pricing: We offer bulk pricing and wholesale discounts for large orders. Please inquire with our sales team for more details.
Q: What is your shipping and delivery process?
Q: What is your shipping and delivery process?
A: Shipping and Delivery: We have a streamlined shipping and delivery process to ensure prompt and efficient delivery of our tarpaulin products to customers. Shipping details can be provided upon order placement.
